O LX192LC e o LX128LC possuem um design 3 em 1 com dupla sonda, combinando presets convexos, lineares e cardíacos. Essa versatilidade permite alternar rapidamente entre modos de imagem para exames abdominais, vasculares, musculoesqueléticos (MSK) e cardíacos, possibilitando diagnósticos rápidos.
O LX128LP é um ultrassom portátil sem fio, otimizado para avaliações cardíacas e vasculares. Seu design compacto, imagens nítidas e inicialização rápida possibilitam diagnósticos rápidos.
 |
 |
 |
||||
|---|---|---|---|---|---|---|
| LX192LC | LX128LC | LX128LP | ||||
| L12-5 | C5-2 | L12-5 | C5-2 | L12-5 | P4-2 | |
| Frequency Bandwidth | 4.2 - 12.5 MHz | 2.0 - 5.0 MHz | 4.2 - 12.5 MHz | 2.0 - 5.0 MHz | 4.2 - 12.5 MHz | 1.3 - 3.7 MHz |
| Max Depth | 18.8 cm | 30 cm | 12.6 cm | 30 cm | 12.6 cm | 30 cm |
| Field of View | - | 60° | - | 60° | - | 90° |
| Wi-Fi | 802.11 a/b/g/n (2.4GHz, 5GHz) | |||||
| Display mode | B mode, M mode, Color Doppler*, Power Doppler*, Pulsed Wave* | |||||
| Battery Working Time | Up to 2 hours | |||||
| Dimension | 145 x 70 x 34 mm | 145 x 70 x 34 mm | 147 x 70 x 34 mm | |||
| Weight | 278 g | 278 g | 266 g | |||
| Waterproofing & Dustproofing | IP67 | |||||
※ Availability depends on different regions.
※ *Optional
※ ※ LX series are splash, water, and dust resistant and were tested under controlled laboratory conditions with a rating of IP67 under IEC standard 60529 (maximum depth of 1 meter up to 30 minutes). Splash, water, and dust resistance are not permanent conditions. Resistance might decrease as a result of normal wear. Do not attempt to charge a wet probe; refer to the user guide for cleaning and drying instructions. Liquid damage is not covered under warranty.
